What is cement made of, Type and Cement ingredients

What is Cement

Cement is a finely powdered hydraulic binder used in concrete and mortar. When mixed with water, it forms a paste that binds fine and coarse aggregates in concrete and binds sand or other suitable fine materials in mortar. Cement paste sets and hardens through hydration reactions; it is not simply a glue that bonds soil and aggregate.

Its is different from lime (CaO) by properties that it is set readily but not slake. The setting power of cement is better than lime. Cement is a Calcareous material which is used in concrete & mortar for construction.

Types of Cement

What is cement

Different types of cement are given below which are classified by its properties and the relevant Indian Standard.

  • Ordinary Portland Cement (opc cement)
  • Rapid Hardening Cement
  • Low Heat Cement
  • Sulphate Resisting Cement
  • Quick Setting Cement
  • High Strength Cement
  • Portland Pozzolana Cement
  • High Alumina Cement
  • White Cement

Ingredients of cement

Mostly 8 type of ingredients is used to make Cement.

  • Lime
  • Silica
  • Alumina
  • Magnesia
  • Sulphur trioxide
  • Iron Oxide
  • Calcium sulphate
  • Alkaline

Note:- Normally Portland Cement is used for building and construction so we read about Portland Cement.

What is portland cement?

Portland cement is a hydraulic binder: it reacts with water and sets and hardens through hydration, including when kept under water after placement. Its principal raw materials commonly include limestone and clay or shale, with corrective materials such as silica-bearing sand and iron-bearing materials added when needed to obtain the required chemical composition.

Portland Cement Manufacturing process

There are two way to manufacturing of cement known as “Wet” & “Dry” which are depending upon the whether mixing and grinding of materials.

Wet Process of Cement Manufacturing

In this process limestone crushed first to smaller fragments. Then put it in ball or tube mill where they mixed with clay & fine ground material. After that water is added to make slurry after that it pumped to slurry tank.

Slurry sprayed against hot surface of flexible chain; losses moisture become flakes in this process temperature reached up to 1500⁰C.

After that process material cooled under controlled conditions that fused material known as Clinker. Cooled clinker then ground in a ball mill with addition of 2 to 3% of gypsum.

Dry Process of Cement Manufacturing

According to its name in this process the raw material for cement is dried and ground to powder by grinding mill. Dry powder is blended and corrected for its right composition and mixed by table.

OxidePercentage
Lime60-67%
Silica17-25%
Alumina3-8%
Iron Oxide0.5–0.6%
Magnesia1-3%
Sulphur Trioxide1-3%
Calcium Sulfate0.1–0.5%

During clinker burning, the raw-meal oxides react at high temperature to form the main clinker phases, commonly described using Bogue’s compounds: tricalcium silicate (C₃S), dicalcium silicate (C₂S), tricalcium aluminate (C₃A), and tetracalcium aluminoferrite (C₄AF). These are clinker phases, not ingredients that are simply mixed together as separate powders.

List of Bogue’s compound.

  1. Tricalcium silicate
  2. Dicalcium silicate
  3. Tricalcium aluminate
  4. Tetra calcium aminopherase.

Mixing of these compounds to make Portland Cement.
